Cooler Master GX 550W BRONZE 5年保養 80 PLUS+ High Eifficiency 85% 用料好 火數足 轉換率高 sata

林公子 於 2014-12-08 18:30:35 發表  |  累積瀏覽 1131

分類:影音電器

Cooler Master GX 550W BRONZE 5年保養 80 PLUS+ High Eifficiency 85% 用料好 火數足 轉換率高 sata

我地呢類打機執相用的電腦,火牛係好重要的其中一環
一定唔可以慳,幾貴都買隻供電足,穩定又寧靜的火牛

雖然要500幾,但係用到幾年條數都係返度

商品賣點:
12V單路式設計 45A PSU。

保固:5年保固 免費送修,直接換全新
風扇使用12CM,安靜。




 http://www.price.com.hk/product.php?p=116823




型號 RS-550-ACAA
類型 Intel Form Factor ATX 12V V2.31
尺寸 (寬 / 高 / 深) 150 x 140 x 86mm
5.9 x 5.5 x 3.4 inch
輸入電壓 90-264Vac (Auto Range)
輸入電流 7A@115Vac, 5A@230Vac
輸入頻率 47-63Hz
功率因素校正(PFC) Active PFC (>0.9)
電源良好信號 100~500ms
延遲時間 >17ms
功率 85% typical
平均故障間隔(MTBF) >100,000 hours
保護 OVP / UVP / OPP / OTP / SCP
輸出容量 550W
最大輸出容量 650W
作業溫度 0~40°C (Nominal Input Voltage)
Regulatory TUV / CE / UL / FCC / BSMI / GOST / C-tick / CCC / KCC
風扇 120mm
Certifications 80 PLUS
接頭 20+4 Pin MB x 1
4+4 Pin CPU 12V x 1
6+2 Pin PCI x 2
SATA x 6
4 Pin Peripherial x 3
4 Pin Floppy x 1
功率:
550W
電源接口:
20+4 Pin MB x 1 4+4 Pin CPU 12V x 1 6+2 Pin PCI x 2 SATA x 6 4 Pin Peripherial x 3 4 Pin Floppy x 1

 詳細資料,轉換率高

 用上靚料

Model RS-550-ACAA-D3
Type Intel Form Factor ATX 12V V2.31
Dimension (W x L x H) 150 x 140 x 86 mm
5.9 x 5.5 x 3.4 inch
Input Voltage 90-264Vac (Auto Range)
Input Current 7A@115Vac, 5@230Vac
Input Frequency Range 47-63Hz
PFC Active PFC (>0.9)
Power Good Signal 100~500ms
Hold Up Time >17ms
Efficiency 85% typical
MTBF >100,000 hours
Protection OVP / UVP / OPP / OTP / SCP
Output Capacity 550W
Max. Output Capacity 660W
Operation Temperature 0~40°C (Nominal Input Voltage)
Regulatory TUV / CE / UL / FCC / BSMI / GOST / C-tick / CCC / KCC
Fan 120mm
Certifications 80 PLUS
Connector 20+4 Pin MB x 1
4+4 Pin CPU 12V x 1
6+2 Pin PCI x 2
SATA x 6
4 Pin Peripherial x 3
4 Pin Floppy x 1

  • Single 12 V Power Rail
    Tackling challenges from the most power-intensive peripherals head on, this solitary 12 V power rail provides ample power and strong resistance to any overloading.

  • Double-Layer EMI Filter
    Dual protection from electromagnetic interference, thus restraining noise and interference for greater protection for you and your connections.

  • Intel Compliant
    ATX12V v 2.3 and EPS version 2.91 compliant.

  • Intelligent Fan Speed Control
    Speed control makes the 120 mm fan adept for any user’s circumstances and need.

  • Active PFC+ PWM Combo Controller
    Integrating this active controller will increase the efficiency of any computer, making PFC higher than 99%.

  • Multiple Protection Design
    Over Voltage Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), Over Temperature Protection (OTP) and Short Circuit Protection (SCP).

  • Massive Bulk Capacitor
    Producing hold times >17ms upon full loading.

  • Efficient Transformer
    - Adeptly holding power for minimal loss in the 5V standby voltage so the system is promptly up and ready from power on or sleep modes
    - Highly efficient design on par with 80Plus requirements (85% typical)

  • And More
    - Multiple updated connectors for all types of interfaces (PCIe, SATA etc.)
    - High reliability with an MBTF of at least 100,000 hours of use.
    - NVIDIA SLI-Ready Certified guarantees enough ample power and up-to date connectors for SLI graphics cards.
    - Five Year Warranty.
